RCP 50 Ton C Frame Power Press –
Engineered Power for Demanding Metal Forming Tasks
The RCP-50T is a high-tonnage 50 Ton C-Frame Mechanical Power Press designed to meet the demands of large-scale, high-precision manufacturing. With advanced features and a robust build, it’s perfect for large industrial applications that require maximum force and precision.
Key Features of RCP-50T C-Frame Power Press
Tonnage Capacity
50 Ton – perfect for heavy-duty industrial tasks
Heavy-Duty Construction
Built for high performance and durability
Mechanical Efficiency
Smooth, precise, and quiet operation
Precision Stroke Control
Adjustable stroke for maximum accuracy
Safety Mechanisms
Equipped with enhanced safety features for operator protection
RCP-50T Press Machine Specifications
Specification
Details
Model No.
RCP-50T
Tonnage
50 Ton
Crank Shaft Diameter
120 mm
Stroke Length
120 mm
Stroke Adjustment
40 – 120 mm
Bed Size
700 × 400 mm
Specification
Details
Distance Bed to Ram
450 mm
Hole in Ram
75 mm
Hole in Bed
150 mm
Flywheel Diameter
800 mm
Motor H.P. Required
15 HP
Dimensions (L×W×H)
1600 × 1400 × 2200 mm
Specification
Details
Model No.
RCP-50T
Tonnage
50 Ton
Crank Shaft Diameter
120 mm
Stroke Length
120 mm
Stroke Adjustment
40 – 120 mm
Bed Size
700 × 400 mm
Distance Bed to Ram
450 mm
Hole in Ram
75 mm
Hole in Bed
150 mm
Flywheel Diameter
800 mm
Motor H.P. Required
15 HP
Dimensions (L×W×H)
1600 × 1400 × 2200 mm
Buy RCP-50T Power Press Machine Online
Reach out to Rajesh Machine Tools for factory pricing, smooth order processing, and swift delivery.
Applications of RCP-50T
- Aerospace & aeronautic industries
- Electrical engineering and electrical appliances
- Iron and steel production
- Non-ferrous metal production
- Rolling mills
- Ship building
- Steel and aluminum construction
- Mechanical engineering
- Electrical engineering and electrical appliances
- Air conditioning, air cooler, cooling towers etc
- Automotiv industry and its suppliers / vendors
- Heating & ventilation industry
- Furniture industry
- Sheet metal products, components & assemblies
Why Choose Rajesh RCP-50T Power Press?
High-End Engineering
Designed for tough industrial environments
Durable Build
Long-lasting performance with minimal downtime
High Productivity
Perfect for large batch production
Nationwide Support
Strong after-sales service network
What is the Price of the RCP-50T C-Frame Power Press?
Contact us for a tailored quote based on your production needs.
